Choose from our range
Features and Benefits:
Compact Polycarbonate offers an edge in many applications by virtue of its many salient virtues. Below are a few:
Strength to weight ratio 200 times, superior to glass
Flame resistance
Weather resistance and UV Protection
Performance from -40 to 120◦C
Exceptional Light Transmission:
Extreme clarity ensures excellent light transmission. Solid polycarbonate sheets with light transmission up to 90% compares favorably with glass. UV protection film aids in resistance against yellowing and loss of light transmission.
High Impact Strength:
Solid structure gives higher impact strength than other plastic sheets or hollow polycarbonate sheets. Also being leak-proof, its impact strength is about 200 times as much as common glass, and about 10 times stronger than toughened glass.
UV Coated:
50 microns UV coating on both sides to protect from harmful rays
Thermal Insulation:
Polycarbonate sheets have lower thermal conductivity (K-valve), hence reducing the loss of heat. It is used in buildings to provide cool summers and warm winters, thus cutting down on electricity costs significantly.
Product Specifications
| Characteristics | Unit | Physical Properties |
|---|---|---|
| Light transmission | % | 88-92 |
| Impact Strength | J/m | 50 |
| Coefficient of thermal expansion | mm/m · °C | 0.065 |
| Heat Conductivity | W/m2 · °C | 0.21 |
| Service Temperature | °C | -40 to +120 |
| Tensile Strength | n/mm2 | ≥60 |
| Bending Strength | n/mm2 | 100 |
| Bending Elastic Modulus | mpa | 2400 |
| Tensile Stress at break | mpa | ≥130 |
| Elongation at break | % | ≥130 |
Sizes & Customizations
Colours
Bronze | Brown | Clear | Blue | Yellow | Green | Greenish Blue
Standard Thickness
1 mm to 10 mm (Customisable subject to MOQ)
Standard Width
1.22 mtr, 1.52 mtr, 1.83 mtr, 2.1 mtr
(Customisable subject to MOQ)
Standard Length
A) 2.44mtr, 3.05mtr, 3.65 mtr – Sheets
B) 15.25 mtr & 30.5 mtr – Coils/Rolls
(Customisable subject to MOQ)
Standard Thickness
1.5 mm, 2 mm
Standard Width
1.22 mtr and 2.1 mtr
Standard Length
A) 2.44 mtr, 30.5 mtr, 3.65 mtr – Sheets
B) 15.25 mtr and 30.5 mtr – Coils/Rolls
(Customisable subject to MOQ)
Colours
Opal | White | Silver | Grey
Standard Thickness
1 mm to 10 mm (Customisable subject to MOQ)
Standard Width
1.22 mtr, 1.52 mtr, 1.83 mtr, 2.1 mtr
(Customisable subject to MOQ)
Standard Length
15.25 mtr & 30.5 mtr
(Customisable subject to MOQ)
